T215HVN05.1 21.5″ FHD LVDS TFT-LCD Open Cell for industrial display
T215HVN05.1 is a 21.5-inch FHD TFT-LCD display with 1920 × 1080 resolution, VA mode and LVDS interface. It supports display sourcing, replacement evaluation and technical review requirements. Request the current specification and verify key design-in parameters before final selection.
21.5 Inch FHD TFT-LCD
T215HVN05.1 is a 21.5 inch FHD 1920×1080 a-Si TFT-LCD display component with a dual channel LVDS interface, supplied through Vernon as a China sourcing partner for LCD display procurement and technical evaluation. The values on this page come from the currently registered specification for this model; request the current specification before design-in or quotation.
21.5″Display size
1920×1080FHD resolution
VA ModeDisplay mode
Dual channel LVDSSignal interface
Key Specifications
Use the model, size, resolution, panel technology and display mode for initial selection. Every figure below has to be checked against the revision you actually intend to order; on mobile, swipe the table sideways to read each value.
| Model | T215HVN05.1 |
|---|---|
| Size | 21.5 inch |
| Resolution | 1920 x 1080 |
| Resolution Class | FHD (1080p) |
| Panel Type | a-Si TFT-LCD |
| Display Mode | VA Mode, Normally Black |
| Active Area | 476.064 (H) x 267.786 (V) mm |
| Pixel Pitch | 247.95 (H) x 247.95 (V) µm |
| Display Colors | 16.7M (RGB 6-bit + Hi-FRC) |
| Surface Treatment | Anti-glare, 3H |
| Interface | Dual channel LVDS |
| Operating Temperature | 0 to +50 °C |
| Storage Temperature | -20 to +60 °C |
All values are typical and subject to the current datasheet or confirmed configuration. Values marked † are taken from the currently registered specification for T215HVN05.1 and are subject to revision verification against the latest datasheet before design-in. Product form, brightness, outline dimensions, power and weight are not yet confirmed for this revision and are therefore not listed here; request the current specification and confirm them before quotation or sampling.
Applications & Buyer Fit
Start with T215HVN05.1 when your requirement is this exact model, or when you are screening a 21.5 inch FHD display component against a fixed enclosure or an existing design. Vernon is a China sourcing partner for LCD and TFT-LCD display procurement, so the evaluation on this page is built on confirmed model identity and the currently registered specification rather than on assumptions about the end product.
The four evaluation paths buyers use most often with this model:
- Exact-model sourcing — T215HVN05.1 is already on your drawing, label or approved vendor list and you need a supply route for that same model identity.
- Existing display replacement evaluation — send the model you are replacing together with a label photo and the current specification so the mechanical, electrical and optical requirements can be compared. The same size or resolution alone is not treated as confirmation of replacement compatibility.
- Controller and enclosure review — confirm the signal interface, cable definition, backlight arrangement, power supply and the space available in the enclosure before a sample is approved.
- Project-specific requirements — brightness, quantity, destination market and schedule can be reviewed and quoted for the configuration your project actually needs.
This page does not state that T215HVN05.1 is proven for a particular end product or industry. Suitability has to be confirmed against your own design, with the current specification as the reference for that review.
Integration Verification Notes
The current specification records a dual channel LVDS interface for T215HVN05.1. An interface name on its own does not establish electrical compatibility, so work through the following points against the revision you intend to order.
- Signal interface — match the registered interface with the controller or embedded mainboard you are using, and confirm the data format and bit depth your design expects.
- Connector and pin assignment — request the connector part, pin assignment and mating connector for the revision being quoted. A matching pin count on its own is not proof of compatibility.
- Controller timing — check the timing, clock range and frame-rate settings recorded for that revision against your controller configuration.
- Mechanical arrangement — check the active area, mounting direction and enclosure clearance against your design. The outer outline and thickness are not yet confirmed for this revision, so take them from the current drawing rather than from this page.
- Backlight requirements — confirm whether the backlight is supplied with the part or provided and driven by your own system, and how brightness is then controlled.
- Power and start-up sequence — confirm the supply rail, power consumption and the power-on/off sequence required by that revision.
Request the current specification and record the revision and label marking of the parts you receive before sample approval or production release.
Brightness Configuration Inquiry
Screen brightness for T215HVN05.1 is a configuration decision rather than a single published value. The registered evidence for this model does not carry one confirmed luminance figure, and different brightness targets can require different backlight, electrical, thermal and mechanical arrangements. Vernon does not publish a confirmed brightness figure for this model, and a target brightness is handled as a requirement to be verified with the supplier rather than as a guaranteed supply specification.
If your project depends on a specific brightness, include the following with your inquiry so the configuration can be reviewed properly:
- The brightness level you need, the unit it is quoted in, and the measurement basis you are working to.
- Whether the figure is a minimum, a typical or a target value for your design.
- The operating environment: ambient light, duty cycle, thermal conditions and expected service life.
- The power budget, driver and backlight control available in your system.
- Mechanical clearance and mounting constraints inside the enclosure.
- Target quantity and schedule, so the configuration can be reviewed for the build you need.
Vernon will confirm what can be supported for the requested configuration. A brightness figure is only settled once it is stated in the current specification for the configuration you order; until then it should be treated as something to verify rather than as a published specification.
Alternative Sourcing Options
If T215HVN05.1 is not available for your requirement, or you need a different display, send the original model and your project constraints for a separate sourcing review. The same size or resolution does not establish replacement compatibility.
T215HVN05.1 Buyer FAQ
How can I verify that this is the exact model I need?
Match the T215HVN05.1 marking and revision on the label or drawing with the current specification, then compare the active area and the outer outline with the part you are working from. Model identity and the revision you actually order both have to line up; 21.5 inch size and FHD resolution on their own are not enough.
What should be checked before replacing an existing display?
Collect the model you are replacing, a label photo, the current specification and your mechanical drawing. Interface, connector and pin assignment, timing, power, backlight arrangement and mounting all have to be compared before approval. Replacement suitability is reviewed separately from this page and is not a drop-in guarantee.
Can Vernon evaluate a brightness requirement?
Yes. State the brightness you need, the measurement basis and the environment the display will work in. The configuration that meets it, including backlight and power, is confirmed with the supplier for your project, so a brightness target is reviewed as a requirement rather than read from this page.
What information is required for a quotation?
Send the exact model, the quantity, the destination market and your target schedule, together with the configuration details that matter to your design: interface, mechanical constraints, brightness requirement, and whether you need a sample. A label photo and the current specification help the review move faster.
What should be verified before design-in?
Confirm the revision you are ordering, the active area and outer outline drawing, the interface and connector definition, timing, power and the complete backlight arrangement, then run a sample in your own system and record the result before final approval. Sourcing an exact model does not by itself establish drop-in compatibility.
Send Your T215HVN05.1 Inquiry
Send the quantity, destination market and schedule, and say whether you need the current specification, a sample or a quotation. If the requirement is a replacement, include the model you are replacing and a label photo, and add the brightness, interface or mechanical constraints that matter so the reply covers the points you still need to verify.
