M270HVN02.0 27″ FHD LVDS Open Cell for industrial display
M270HVN02.0 is a 27 inch FHD 1920×1080 TFT-LCD display with a VA Mode, Normally Black panel and a 2-channel LVDS interface, listed in the Vernon display sourcing catalogue. Request the current specification, sourcing support and technical evaluation before design-in or quotation.
27 Inch FHD TFT-LCD
M270HVN02.0 is a 27 inch FHD 1920×1080 TFT-LCD display with a VA Mode, Normally Black panel and a 2-channel LVDS interface, listed in the Vernon display sourcing catalogue. The values on this page come from the currently registered specification for this model; request the current specification before design-in or quotation.
27″Display size
1920×1080FHD resolution
VA ModeDisplay mode
LVDSSignal interface
Key Specifications
| Model | M270HVN02.0 |
|---|---|
| Size | 27 inch |
| Resolution | 1920 x 1080 |
| Resolution Class | FHD (1080p) |
| Panel Type | TFT LCD, VA Mode, Normally Black |
| Pixel Pitch | 311.25 (H) x 311.25 (V) µm |
| Display Colors | 16.7M (RGB 8-bit) |
| Response Time | 12 ms typical (on/off) |
| Surface Treatment | Anti-Glare, 3H |
| Interface | 2-channel LVDS (30-pin) |
| Nominal Input Voltage | 5 V (Typ., VDD) |
| Power | 5.1 W (Typ., VDD line, all-white pattern at 60 Hz) |
| Weight | 630 g (Typ.) |
| Operating Temperature | 0 to +50 °C |
| Storage Temperature | -20 to +60 °C |
The values above are taken from the currently registered specification for M270HVN02.0 and are subject to revision verification. Fields that are not listed on this page — including active area, outline dimensions, contrast ratio, colour gamut, absolute brightness and certified compliance — are not yet confirmed for this revision and should be verified against the latest datasheet before design-in, sampling or quotation.
Applications & Buyer Fit
M270HVN02.0 is a 27 inch class FHD TFT-LCD display for buyers who need to evaluate a display with a VA Mode, Normally Black panel and a 2-channel LVDS interface. The registered specification covers the fields used for first-stage screening here: size, resolution, resolution class, panel type and display mode, pixel pitch, display colours, response time, interface, power, weight and operating temperature.
Suitable for evaluation in display sourcing and integration projects where the exact mechanical, electrical and optical requirements are confirmed before design-in. Tell Vernon your application, quantity and the required mechanical, electrical and optical conditions and the sourcing team can review them against the current specification.
Interface & Integration Notes
The current specification records a 2-channel LVDS interface with a 30-pin connector for this model. For project evaluation, match the display with your mainboard interface, cable definition, power and backlight requirements, and mechanical mounting direction before confirming a sample or bulk order.
- Confirm the signal interface, connector type and pin definition against the selected control board or embedded mainboard.
- Check the active area and the mechanical outline against the enclosure design, and request the current drawing for this revision.
- Confirm cable, backlight, driver board and power requirements before design-in.
- Request the current specification and confirm the revision you intend to order.
Alternative Sourcing Options
No related model is published on this page for M270HVN02.0, because a similar size class or resolution is not by itself confirmation of compatibility. Send the details below and Vernon will review sourcing options with you:
- Exact model and, where available, a label photo
- Current datasheet or specification
- Required size, resolution and interface
- Mechanical constraints and mounting direction
Frequently Asked Questions
How can I request the current specification for M270HVN02.0?
Send your requirement through the inquiry form or by email and Vernon can provide the currently registered specification for M270HVN02.0 together with the revision details available for this model. Specifications should be verified against the current document revision before design-in, sampling or quotation.
What information should be checked before design-in?
The mechanical outline and mounting direction, active area, signal interface and connector definition, power and backlight requirements, and the operating temperature range for your enclosure. Several of these fields are not yet confirmed for the currently registered revision of M270HVN02.0, so confirm them against the latest datasheet before committing to a design.
Can Vernon help evaluate M270HVN02.0 for replacement sourcing?
Yes. Replacement and alternative-model evaluation is handled separately from this page. Share the existing model, a label photo, the current datasheet and the required size, resolution, interface and mechanical constraints, and Vernon will review the sourcing options with you.
How should compatibility with an existing display be verified?
A similar size, resolution or interface name is not by itself confirmation of compatibility. Electrical and mechanical fit — outline, mounting, connector, pinout, power and backlight — must be checked against the current specification for both models before any commitment.
What information should I provide with my RFQ?
Include the exact model, quantity, target application and destination market, plus whether you need the datasheet, a sample or a quotation. A label photo, the current datasheet and your mechanical and interface requirements help Vernon review the request faster.
Send Your M270HVN02.0 Inquiry
Share your quantity, target application, destination market, and whether you need the specification, sample or quotation. Vernon can review the current revision and requested configuration details.
Send Inquiry
Please send your inquiry for M270HVN02.0 using the form below. Our team can help confirm the current specification, revision status, sample requirements, and cable and power requirements.
