MV270FHB-N20 27″ FHD LVDS TFT-LCD Open Cell for industrial display
Suitable for equipment manufacturers and system integrators needing a 27″ Full-HD LVDS / Mini-LVDS TFT-LCD open cell for industrial display projects.
27 Inch FHD TFT-LCD Open Cell
MV270FHB-N20 is a 27 inch FHD a-Si TFT-LCD open cell panel with LVDS / Mini-LVDS interface, for industrial display applications.
27″Display size
1920×1080FHD resolution
LVDSSignal interface
72% NTSCColor gamut
Key Specifications
| Model | MV270FHB-N20 |
|---|---|
| Size | 27 inch |
| Resolution | 1920 x 1080 |
| Resolution Class | FHD (1080p) |
| Panel Type | a-Si TFT-LCD |
| Form | Open Cell |
| Active Area | 597.888(H) x 336.312(V) mm |
| Pixel Pitch | — |
| Display Colors | 16.7M |
| Interface | LVDS / Mini-LVDS |
| Contrast Ratio | 700:1 |
| Color Gamut | 72% NTSC |
| Power | — |
| Weight | — |
| Operating Temperature | 0 ~ +50°C |
| Compliance | — |
All values are typical and subject to the current datasheet or confirmed configuration. Fields marked “—” are not listed in the current Vernon specification database and should be confirmed before quotation or sampling.
Applications & Buyer Fit
MV270FHB-N20 is suitable for buyers who need to evaluate a 27 inch FHD panel with LVDS / Mini-LVDS interface and open cell form. The confirmed page data focuses on the hardware fields needed for first-stage screening: size, resolution, active area, interface, contrast ratio, color gamut, display colors, and operating temperature.
Before sampling, confirm the required backlight solution, cable, driver board, mechanical space, and target enclosure requirements with Vernon. Specific application industries and buyer benefits are not yet filled in the Vernon messaging database, so this page uses a neutral industrial display description rather than unconfirmed claims.
Interface & Integration Notes
This model uses an LVDS / Mini-LVDS interface. For project evaluation, match the open cell with your mainboard interface, cable definition, backlight and power requirements, and mechanical mounting direction before confirming sample or bulk order.
- Confirm LVDS / Mini-LVDS compatibility with the selected control board or embedded mainboard.
- Open cell form: confirm the backlight assembly and bonding scope on your side.
- Check active area and mechanical space against the enclosure design.
- Request the latest datasheet before final design-in.
Related Vernon Models
For alternative evaluation, compare MV270FHB-N20 with the related 27 inch FHD LVDS model below. Vernon can help confirm which option better matches your interface, mechanical design and sourcing requirement.
Send Your MV270FHB-N20 Inquiry
Share your quantity, target application, destination market, and whether you need datasheet, sample, or quotation. Vernon will confirm availability and suitable configuration details.
Send Inquiry
Please send your inquiry for MV270FHB-N20 using the form below. Our team can help confirm datasheet, sample availability, backlight, cable and driver board requirements.
