HV320WHB-F56 32″ HD LVDS TFT-LCD Open Cell for industrial display
Suitable for equipment manufacturers and system integrators needing a 32″ HD LVDS TFT-LCD open cell for industrial display projects.
32 Inch HD TFT-LCD Open Cell
HV320WHB-F56 is a 32 inch HD a-Si TFT-LCD open cell with LVDS / Mini-LVDS interface, for industrial display applications.
32″Display size
1388×768HD resolution
LVDS / Mini-LVDSSignal interface
900:1Contrast ratio
Key Specifications
| Model | HV320WHB-F56 |
|---|---|
| Size | 32 inch |
| Resolution | 1388 x 768 |
| Resolution Class | HD |
| Panel Type | a-Si TFT-LCD |
| Form | Open Cell |
| Active Area | 697.685(H) x 392.256(V) mm |
| Pixel Pitch | 170.25(H) xRGBx510.75 |
| Display Colors | 16.7M |
| Interface | LVDS / Mini-LVDS |
| Contrast Ratio | 900:1 |
| Color Gamut | — |
| Power | — |
| Weight | — |
| Operating Temperature | — |
| Compliance | — |
All values are typical and subject to the current datasheet or confirmed configuration. Fields marked “—” are not listed in the current Vernon specification database and should be confirmed before quotation or sampling.
Applications & Buyer Fit
HV320WHB-F56 is suitable for buyers who need to evaluate a 32 inch HD open cell with LVDS / Mini-LVDS interface. The confirmed page data focuses on the hardware fields needed for first-stage screening: size, resolution, active area, panel type, interface, display colors, and contrast ratio.
Before sampling, confirm the required backlight, driver board, cable definition, mechanical space, and target enclosure requirements with Vernon. Specific application industries and buyer benefits are not yet filled in the Vernon messaging database, so this page uses a neutral industrial display description rather than unconfirmed claims.
Interface & Integration Notes
This model uses an LVDS / Mini-LVDS interface. For project evaluation, match the open cell with your mainboard interface, cable definition, backlight driver requirements, and mechanical mounting direction before confirming sample or bulk order.
- Confirm LVDS / Mini-LVDS compatibility with the selected control board or T-CON / mainboard.
- Check active area and mechanical space against the enclosure design.
- Request the latest datasheet before final design-in.
Related Vernon Models
For alternative evaluation, compare HV320WHB-F56 with a related 32-inch-class open cell below. Vernon can help confirm which panel better matches your interface, resolution, mechanical design and sourcing requirement.
Send Your HV320WHB-F56 Inquiry
Share your quantity, target application, destination market, and whether you need datasheet, sample, or quotation. Vernon will confirm availability and suitable configuration details.
Send Inquiry
Please send your inquiry for HV320WHB-F56 using the form below. Our team can help confirm datasheet, sample availability, cable and backlight driver requirements.
