NV156FHM-N4V 15.6″ FHD TFT-LCD Module
NV156FHM-N4V is an LCD display product available through Vernon for display sourcing, display procurement and technical evaluation projects. The model is registered in the Vernon product catalog, and its technical fields are still under verification, so Vernon publishes no unverified specification for it. Tell us your target application, quantity and required revision, and Vernon will provide the current specification, technical evaluation and sourcing support before design-in.
15.6 Inch FHD TFT-LCD Module
NV156FHM-N4V is a 15.6 inch FHD a-Si TFT-LCD display module with a 1920 x 1080 resolution and eDP interface, supplied by Vernon for display sourcing and technical evaluation projects. The published specifications below support first-stage screening; request the current specification to confirm the revision you would receive.
15.6″Display size
1920×1080FHD resolution
eDPSignal interface
45%Color gamut
Key Specifications
| Model | NV156FHM-N4V |
|---|---|
| Size | 15.6 inch |
| Resolution | 1920 x 1080 |
| Resolution Class | FHD (1080p) |
| Panel Type | a-Si TFT-LCD |
| Display Mode | Normally Black |
| Form | Module |
| Active Area | 344.16(H) x 193.59(V) mm |
| Pixel Pitch | 179.25(H) x 179.25(V) |
| Display Colors | 262K (6bit) |
| Color Gamut | 45% |
| Interface | eDP |
| Outline Dimensions | 350.66(H) x 205.69(V) x 5.4(Max) mm (with PCB) |
| Operating Temperature | 0 ~ +50°C |
All values are typical and subject to the current datasheet or confirmed configuration. Values marked † are taken from the currently registered specification for NV156FHM-N4V and are subject to revision verification against the latest datasheet before design-in. Fields not listed here are not yet confirmed for this revision and should be verified against the latest datasheet before design-in or quotation.
Applications & Buyer Fit
NV156FHM-N4V is suitable for buyers who need to evaluate a 15.6 inch FHD module with eDP interface. The published page data focuses on the hardware fields needed for first-stage screening: size, resolution, active area, interface, color gamut, display colors, display mode, outline dimensions and operating temperature.
Before sampling, confirm the required cable, driver board, backlight control, mechanical space and target enclosure requirements with Vernon. Specific application industries and buyer benefits are not filled in for this model, so this page uses a neutral display description rather than unconfirmed claims.
Interface & Integration Notes
This model uses an eDP interface, and the current registered specification records a 2-lane eDP1.2 interface, an on-board LED driving circuit and an on-board EDID chip. For project evaluation, match the display module with your mainboard interface, cable definition, power and backlight requirements, and mechanical mounting direction before confirming a sample or bulk order.
- Confirm eDP compatibility with the selected control board or embedded mainboard.
- Check the active area, outline dimensions and mechanical space against the enclosure design.
- Request the latest datasheet before final design-in.
Technical Evaluation Notes
How to evaluate NV156FHM-N4V for your project
The specifications above come from the currently registered exact-model specification for NV156FHM-N4V. Use them for first-stage screening, then confirm size, resolution, interface, panel technology and product form against your own requirement list.
- Confirm active area, outline dimensions, mounting and cable routing against your mechanical design.
- Confirm electrical, backlight, driver and cable requirements against your board design.
- Confirm operating environment and any certification requirement against your target application.
- Ask Vernon for the current specification of NV156FHM-N4V and confirm the exact revision you are evaluating.
Specifications, revisions and configurations can change. Request the current specification before design-in; values published elsewhere may not match the revision Vernon can currently supply.
Frequently Asked Questions
What is NV156FHM-N4V?
NV156FHM-N4V is a 15.6 inch FHD TFT-LCD display module with a 1920 x 1080 resolution and eDP interface, supplied by Vernon for display sourcing and display procurement projects.
Can you send the datasheet or specification for NV156FHM-N4V?
Yes. Request the current specification and Vernon will confirm the revision and the available technical details for this model, including any field that is not published on this page.
Which interface and resolution does this module use?
The currently registered specification for this model records a 1920 x 1080 FHD resolution with an eDP interface. Confirm the exact revision with Vernon before design-in.
Is NV156FHM-N4V compatible with my current display?
Compatibility is not assumed from the model name, size or resolution. Send your current model and datasheet so Vernon can compare interface, mechanical and electrical requirements with you. Compatibility must be confirmed at interface, mechanical, electrical and firmware level.
How do I get a quotation for NV156FHM-N4V?
Send your quantity, target application and destination market through the inquiry form below or by email, and Vernon will follow up with quotation and sourcing support.
Related Vernon Models
For alternative evaluation, compare NV156FHM-N4V with the related 15.6 inch FHD module below. Vernon can help confirm which module better matches your interface, mechanical design and sourcing requirement.
Send Your NV156FHM-N4V Inquiry
Share your quantity, target application, destination market, and whether you need the current specification, a sample, or a quotation. Vernon will confirm availability and the suitable configuration details for NV156FHM-N4V.
Send Inquiry
Please send your inquiry for NV156FHM-N4V using the form below. Our team can help confirm the current specification, sample availability, cable and driver board requirements.
