M236HJJ-P02 23.6″ FHD LVDS TFT-LCD Open Cell for industrial display
Suitable for equipment makers and system integrators needing the M236HJJ-P02 23.6″ Full-HD TFT-LCD open cell for industrial display projects.
23.6 Inch FHD TFT-LCD Open Cell
M236HJJ-P02 is a 23.6 inch Full HD (1920×1080) TFT-LCD open cell with a-Si TFT active matrix technology and 16.7M display colors. Its 521.28 × 293.22 mm active area sits inside a 534.280 × 306.252 mm TFT outline. Vernon is a China sourcing partner for buyers evaluating this exact model: confirm the current revision and the mechanical fit before ordering a sample.
23.6″Display size
1920×1080FHD resolution
a-Si TFTPanel technology
16.7MDisplay colors
Key Specifications
Use the model, size, resolution and product form for initial selection. Final electrical and mechanical fit must be checked for the revision you intend to order. On mobile, swipe the table sideways to read each value.
| Model | M236HJJ-P02 |
|---|---|
| Size | 23.6 inch |
| Resolution | 1920 x 1080 |
| Resolution Class | FHD (1080p) |
| Panel Type | a-Si TFT active matrix |
| Form | Open Cell |
| Active Area | 521.28(W) x 293.22(H) mm |
| Outline Dimensions | 534.280(W) x 306.252(H) mm (TFT Outline) |
| Display Colors | 16.7M |
All values are typical and subject to the current datasheet or confirmed configuration. Interface, pin assignment, contrast ratio, color gamut, power, weight and operating temperature are not yet confirmed for this revision; request the current specification and verify it against the latest datasheet before design-in or quotation.
Applications & Buyer Fit
Start with M236HJJ-P02 when your sourcing requirement is this exact model, or when you are screening a 23.6 inch FHD TFT-LCD open cell against a fixed enclosure or an existing design. Compare the label marking, revision and mechanical dimensions with the part you are replacing before you request a sample.
The size, resolution and active area give you a first screen only; they do not establish suitability for a particular application. For display integration and sourcing projects, confirm the operating environment, mounting arrangement and complete assembly requirements before approval.
Need an assembled display unit? Send the required brightness, backlight, control board and enclosure details with your inquiry — the open cell and any assembled configuration are reviewed separately.
Interface & Integration Notes
Confirm the signal interface, connector, pin assignment and cable definition for the exact revision before connecting M236HJJ-P02 to a control board. These items are still open for this revision, so an interface name or a matching pin count alone does not establish electrical compatibility.
- Compare the current interface and timing specification with your controller or embedded mainboard.
- Check the outline drawing, connector position and mounting arrangement against the available enclosure space.
- Verify power and backlight integration for the complete assembly before design-in.
Use our LCD specification verification guide to prepare the documents needed for this review.
Evaluation & Revision Note
Confirm the label, revision and current datasheet for the parts being quoted. The document version and the revision marking on the supplied part have to be checked together before sample approval or production release.
Keep the open cell requirement separate from an assembled display configuration. If brightness, backlight, interface or mechanical constraints are critical, state them in the inquiry and evaluate the proposed configuration before approval.
When a revision change is proposed, re-check mechanical fit, interface definition and timing against your design before accepting it. A matching model number on the label does not confirm that nothing else in the specification moved.
For an existing design, follow the LCD revision change revalidation guidance before accepting a changed revision.
Alternative Sourcing Options
If M236HJJ-P02 is unavailable for your requirement or you need a different display, send the original model and project constraints for a separate sourcing review. The same size or resolution does not establish replacement compatibility.
M236HJJ-P02 Buyer FAQ
Is M236HJJ-P02 an open cell or a complete display module?
M236HJJ-P02 is identified here as a TFT-LCD open cell. If you need a complete display assembly, describe that configuration separately: this page does not confirm backlight, controller or enclosure configuration for it.
How can I check whether this is the correct LCD panel?
Match the M236HJJ-P02 model marking and revision on your label with the current datasheet, then measure the active area and TFT outline against the part you are replacing. Product form, mechanical dimensions and electrical requirements all have to line up; 23.6 inch size and FHD resolution alone are not enough.
Can M236HJJ-P02 replace another display?
Replacement suitability requires a separate technical review. Send the existing model, label photo, current datasheet, controller details and mechanical drawing so electrical, mechanical and optical requirements can be compared before approval. A replacement sourcing review compares requirements; it is not a drop-in guarantee.
What information is required before quotation or sampling?
Send the exact model and product form, quantity, destination market and target schedule. Include a label photo, the current datasheet and the integration requirements that matter to your project. State whether you need the open cell on its own or a separately evaluated assembly, and say whether the next step is a quotation or a sample.
What must be confirmed before design-in?
Confirm the supplied revision, outline and mounting drawing, interface, connector and pin assignment, timing, power and the complete assembly requirements. Run a sample against your own system and record the results before final approval; sourcing an exact model does not establish drop-in compatibility.
Send Your M236HJJ-P02 Inquiry
Send the quantity, target market and schedule, and say whether you need the current datasheet, a sample or a quotation. Vernon will confirm availability and the revision status of the parts quoted, and will flag the points that the datasheet does not settle.
Send Inquiry
Use the form below for M236HJJ-P02. Include your label photo, target quantity and the constraints that matter to your design — mechanical fit, interface, power or assembly — so the reply covers the points you still need to verify.
