| Manufacturer |
BOE |
| Model |
DV430FHM-NN1 |
| Diagonal Size |
43 inch |
| Panel Type |
a-Si TFT-LCD, LCM (Liquid Crystal Module) |
| Active Area |
940.896(H) × 529.254(V) mm |
| Outline Dimension |
961.7(H) × 550.1(V) × 27.7(D) mm |
| Pixel Format |
RGB Vertical Stripe |
| Resolution |
1920(RGB) × 1080, FHD, 16:9 |
| Panel Weight |
8.36 Kgs (Typ.) |
| Surface Treatment |
Haze (1%), Hard Coating (3H) |
| Brightness |
400 cd/m² (Typ.) |
| Customized Backlight Option |
300–700 nits adjustable, based on project requirements |
| Contrast Ratio |
1200:1 (Typ.) (TM) |
| Recommended View |
Full Viewing Angle |
| Response Time |
8 ms (Typ.) (G to G) |
| Viewing Angle |
89° / 89° / 89° / 89° (Typ.) (CR ≥ 10) |
| Display Mode |
ADS, Normally Black, Transmissive |
| Light Source |
WLED, 30K hrs, with LED Driver, DC Dimming |
| Backlight Type |
E-LED (Edge-lit LED) Backlight |
| Color Support |
16.7M, 72% NTSC |
| Application Product |
Display / Monitor Application |
| Refresh Rate |
60 Hz |
| Touch Technology |
No Touch |
| Interface Type |
LVDS (2 ch, 8-bit), 51 pins, Terminal |
| Power Supply |
12.0V (Typ.) |
| Operating Environment |
Operating temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C |
