| Manufacturer |
BOE |
| Model |
MV238FHM-N62 |
| Diagonal Size |
23.8 inch |
| Panel Type |
a-Si TFT-LCD, LCD Module |
| Active Area |
527.04(W) × 296.46(H) mm |
| Outline Dimension |
535(W) × 313(H) × 13(D) mm |
| Pixel Format |
RGB Vertical Stripe |
| Resolution |
1920(RGB) × 1080, FHD, 16:9 |
| Panel Weight |
2200 g (Typ.) |
| Surface Treatment |
Haze 25%, Hard Coating (3H) |
| Brightness |
250 cd/m² (Typ.) |
| Customized Backlight Option |
300–700 nits adjustable, based on project requirements |
| Contrast Ratio |
1000:1 (Typ.) (Transmissive) |
| Recommended View |
Full Viewing Angle |
| Response Time |
14 ms (Typ.) (G to G) |
| Viewing Angle |
89° / 89° / 89° / 89° (Typ.) (CR ≥ 10) |
| Display Mode |
ADS, Normally Black, Transmissive |
| Power Consumption |
11.28 W (Typ.) / 14.11 W (Max.) |
| Backlight Type |
20S4P WLED, 30K hrs, Driver-free |
| Color Support |
16.7M, 100% sRGB |
| Application Product |
Display / Monitor application |
| Refresh Rate |
75 Hz |
| Touch Technology |
No touch |
| Interface Type |
LVDS (2 ch, 8-bit), 30 pins, terminal |
| Power Supply |
5.0V (Typ.) |
| Operating Environment |
Operating temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C |
