| Manufacturer |
BOE |
| Model |
MV270FHB-N20 |
| Diagonal Size |
27.0 inch |
| Panel Type |
a-Si TFT-LCD, LCD Glass, FOB |
| Active Area |
597.888(W) × 336.312(H) mm |
| Outline Dimension |
607.048(W) × 346.642(H) × 1.32(D) mm |
| Pixel Format |
RGB Vertical Stripe |
| Resolution |
1920(RGB) × 1080, FHD, 16:9 |
| Panel Weight |
625 g (Typ.) |
| Surface Treatment |
Anti-glare (Haze 25%), Hard Coating (3H) |
| Brightness |
0 cd/m² |
| Customized Backlight Option |
300–700 nits adjustable, based on project requirements |
| Contrast Ratio |
1000:1 (Typ.) (Transmissive) |
| Recommended View |
Full Viewing Angle |
| Response Time |
14 ms (Typ.) (G to G) |
| Viewing Angle |
89° / 89° / 89° / 89° (Typ.) (CR ≥ 10) |
| Display Mode |
ADS, Normally Black, Transmissive |
| Glass Thickness |
– |
| Transmittance |
5.7% (Typ.) with polarizer |
| Color Support |
16.7M, 99% sRGB |
| Application Product |
Display / Monitor application |
| Refresh Rate |
75 Hz |
| Touch Technology |
No touch |
| Driver IC |
COF, bonded, 8 source chips |
| Interface Type |
LVDS (2 ch, 8-bit), 30 pins, terminal |
| Power Supply |
5.0V (Typ.) |
| Operating Environment |
Operating temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C |
